Our friends at Audinate have announced the release of the Dante AV module - an Audinate module which allows the transport of video along with audio on the same network using the same tools. No more sync issues or need to transport audio and video streams by different means.
With Dante AV, audio and video channels are individually routable using the familiar Dante Controller software, with no need for breakouts or matrix switches. Send audio channels to any of the 1600+ Dante-enabled products currently available while sending video to any number of Dante AV-enabled screens.
Dante AV delivers sub-microsecond synchronisation to video and audio, making time-alignment problems a thing of the past. A single network clock keeps the entire system in sync regardless of the number of endpoints, transporting audio and video with low, deterministic latency.
Dante AV Module
Audio Specs
Up to eight channels at 44.1, 48, 88.2 or 96kHz. HDCP sourced audio channels limited to 48kHz
Up to seven simultaneous audio packet streams
TDM, I2S digital audio formats
Hardware audio metering
High-quality, low jitter with on-board clock generator for audio
Four configurable I2S audio lines
Up to 8192 samples (170ms@48kHz) audio buffering per channel [receiver only]
Built-in eight channel asynchronous sample rate converter [in transmitter only]
Audio transport formats: Dante Audio over IP, AES67 RTP
Bit depths: 24, 16 and 32 bits per audio sample
44.1, 48, 88.2, 96, 176.4 and 192 kHz sample rates
Sample rate pull-up/down (+4.1667, +0.1, -0.1, and - 4.0 %
Video Specs
1-channel 32-bit high speed parallel video interface (transmit or receive)
Built-in HDCP encryption/decryption for video
800Mbps recommended maximum bit rate
Accepts any bit stream from external codec
Video transport formats: Dante Video over IP
